Original Bosch Rexroth CGH2 Series High Quality CGH2MF3/80/45/300D3X/B11HHMWW CGH2MF3/100/56/400D3X/B22HHMWW CGH2MS2/125/70/500D3X/B22HHMWW in Stock
Bosch Rexroth CGH2 Series – Product Introduction
- CGH2MF3/80/45/300D3X/B11HHMWW
- CGH2MF3/100/56/400D3X/B22HHMWW
- CGH2MS2/125/70/500D3X/B22HHMWW
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Series: CGH2 (Component Series 3X)
- Type: Single rod, double‑acting, mill‑type welded hydraulic cylinder
- Nominal Pressure: 250 bar (25 MPa)
- Static Test Pressure: 375 bar
- Standards: DIN 24333, ISO 6022, CETOP RP 73H
- Piston Diameter (ØAL): 40 mm ~ 320 mm
- Rod Diameter (ØMM): 25 mm ~ 220 mm
- Standard Stroke: Up to 3000 mm
- Max. Stroke: Up to 6000 mm (customizable)
- Operating Temp: -20 °C … +80 °C
- Media: Mineral oils (HLP), HFC, HFDR fire‑resistant fluids
- Steel mills & metallurgy: rolling mills, continuous casters, furnace doors
- Heavy machinery: forging presses, extrusion presses, large machine tools
- Marine & offshore: deck machinery, hatch covers, winches
- Automotive: stamping lines, body presses
- Civil engineering: concrete pumps, heavy lifting
- Test rigs & simulation: high‑force structural testing
