Bosch Rexroth CGT3 Series – Double-Rod Tie-Rod Hydraulic Cylinders
Product Overview
The Rexroth CGT3 (Component Series 3X) is a double-rod, tie-rod design hydraulic cylinder engineered for symmetric force/speed and precise linear motion in both directions. It shares the robust T3 platform with CDT3 but features identical piston rods extending from both sides, ideal for synchronized movement, balanced loading, and applications requiring equal performance in extension and retraction.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
Double-Rod Symmetry
- Identical rods on both sides deliver equal force and speed in extend/retract
- Eliminates side loading; ideal for balanced motion, alignment, and synchronization
Modular & Maintenance-Friendly
- Integrated guide bushing for simplified seal replacement
- Patented safety bleeding valve for fast, secure air purging
- Freely rotatable port positions (head/cap) for flexible installation
Flexible Cushioning Options
- U: No cushion
- D: Self-adjusting cushion (auto-optimizes)
- Z: Manual adjustable cushion (both ends)
Wide Mounting Compatibility
- 7 standard mounting styles (ME5, ME6, MS2, MP5, MT4, MX1, MX5)
- Flange, foot, clevis, trunnion, extended tie-rod configurations
