OEM PASCAL Swing clamp CTU01-L CTU02-L CTU04-L CTU06-L CTU10-L CTU16-L CTU25-L FANGU hydraulic cylinders in Stock
The Pascal CTU series is a high‑performance, double‑acting hydraulic swing clamp cylinder designed for rapid workpiece clamping and unclamping in CNC machining centers, automated production lines, and precision fixture systems. It combines a Gothic cam‑slot & ball bearing mechanism for smooth, high‑speed swing motion with robust hydraulic actuation, delivering reliable clamping force at a rated pressure of 7 MPa. Its compact, flange‑mounted design is ideal for dense fixture layouts requiring fast, precise clamping.
Main Models: CTU01-L CTU02-L CTU04-L CTU06-L CTU10-L CTU16-L CTU25-L
Pascal CTU Product Introduction (7MPa Double‑Acting Swing Clamp Cylinder)
Overview
The Pascal CTU series is a high‑performance, double‑acting hydraulic swing clamp cylinder designed for rapid workpiece clamping and unclamping in CNC machining centers, automated production lines, and precision fixture systems. It combines a Gothic cam‑slot & ball bearing mechanism for smooth, high‑speed swing motion with robust hydraulic actuation, delivering reliable clamping force at a rated pressure of 7 MPa. Its compact, flange‑mounted design is ideal for dense fixture layouts requiring fast, precise clamping.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Gothic Cam‑Slot & Ball Bearing: Reduces friction, enables high‑speed swing (up to 180 cycles/min), and extends service life.
- 7MPa Rated Pressure: Delivers strong clamping force in a compact footprint.
- Double‑Acting Hydraulics: Stable, bidirectional actuation for fast clamping/unclamping.
- Multiple Swing Angles: Standard 90°, with 30°, 45°, 60° options for flexible fixture designPascal Engineering.
- Swing Direction: Clockwise (R) or Counter‑Clockwise (L) to match layoutPascal Engineering.
- Chlorine‑Resistant Seals: Withstands harsh cutting fluids for industrial durability.
- Wide Operating Temp: 0–70°C for reliable performance in harsh environments.
- Rod End Options: Threaded (T), Pin (P), or Dual Rod (E) for versatile arm mountingPascal Engineering.
- Air Sensor Ready: Optional air sensing (P) for position confirmation and interlock controlPascal Engineering
