Japan Pascal Brand Link clamp 5MPa Double acting Jump up model CLS-N CLS05-FN CLS06-FN CLS06-FN Hydraulic Products in Stock
The Pascal CLS‑N series is a 5MPa double-acting hydraulic link clamp from PASCAL Japan, featuring a “Jump‑Up + Standard” design. Adopting a linkage lever amplification mechanism and hydraulic double-acting drive, it delivers jump-up clearance, high clamping force, high rigidity, and stable operation.
Main Models: CLS05-FN CLS06-FN CLS06-FN
Product Introduction: Pascal CLS‑N Series Link Clamp (5MPa Double‑acting, Jump‑Up, Standard Type)
Product Overview
The Pascal CLS‑N series is a 5MPa double-acting hydraulic link clamp from PASCAL Japan, featuring a “Jump‑Up + Standard” design. Adopting a linkage lever amplification mechanism and hydraulic double-acting drive, it delivers jump-up clearance, high clamping force, high rigidity, and stable operation. Designed for machine tool machining, tooling fixtures, rapid mold change, and automated production lines, it enables quick clamping, clearance avoidance, and stable fixation of workpieces, serving as a core fixture component for precision machining and automated stations.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- 5MPa low-pressure hydraulic drive: Compatible with standard low-pressure hydraulic systems, low energy consumption, and high safety.
- Double-acting hydraulic control: Hydraulic clamping and unclamping ensure consistent motion without mechanical spring fatigue, suitable for high-frequency continuous operation.
- Jump‑Up structure: The piston rod jumps up for clearance before clamping, avoiding interference with workpieces and enabling smooth loading of special/stepped workpieces.
- Linkage lever amplification: Delivers high clamping force in a compact volume with high rigidity and low vibration to ensure machining accuracy.
- Compact flat-mount design: No embedded machining required, easy installation, and ideal for high-density fixturing.
- High protection sealing: Resists chips, coolant, and cutting fluids for harsh workshop environments.
- Multi-directional mounting: Supports forward (F), left (L), and right (R) mounting for flexible layout.
