The Pascal CTJ is a flat-mount, double-acting hydraulic swing clamp (7 MPa) designed for space-saving, easy piping, and thin fixture plate applications.
The Pascal CTJ is a flat-mount, double-acting hydraulic swing clamp (7 MPa) designed for space-saving, easy piping, and thin fixture plate applications. It eliminates the need for embedded machining on fixture plates, simplifies bottom piping design, and reduces fixture footprint by approximately 29% and piping distance by 38% compared to previous models. With a 90° swing angle (±3°) and left/right (L/R) rotation options, it delivers stable double-acting hydraulic actuation, high reliability, and strong adaptability for unmanned clamping, error-proof machining, and improved production tact in automotive parts, mold, and general mechanical processing lines.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
Flat Mounting, No Embedded Machining Required
No need for embedded holes on the fixture plate, greatly simplifying the design of the fixture base plate. The fixture plate can be made thinner to adapt to narrow installation spaces.
More Convenient Piping, Lower Space Occupancy
The bottom piping design is more flexible. The fixture area is reduced by approximately 29% compared with previous models, and the total piping distance is shortened by about 38%, making it suitable for high-density fixture layouts.
Double-Acting Structure, Stable Operation
Adopting a 7MPa hydraulic double-acting design, the clamping/unclamping actions are driven by hydraulic pressure bidirectionally, featuring smooth movement and fast response, suitable for continuous high-frequency automated cycles.
High Reliability and Adaptability
Inheriting the advantages of the sealing and cam structure of Pascal swing clamps, it is resistant to chips and coolant interference, and is suitable for unmanned clamping and error-proof machining requirements.
Automotive parts processing: Automated clamping of precision components such as engine blocks and transmission housings.
Mold processing: Efficient clamping of die steel and cavity parts to meet the high-frequency mold change requirements of mold workshops.
General mechanical processing: Precision machining stations for hardware parts and sheet metal parts, realizing unmanned continuous production.
