High Quality Pascal Swing clamp 7MPa Double acting Compact Model 5mm Stroke CTM-N CTM-05LN CTM-05RN CTM-06LN CTM-06RN CTM-10LN CTM-10RN in Stock
The Pascal CTM‑N series is a compact, double‑acting hydraulic swing clamp designed for space‑constrained CNC fixtures and automated production lines. As an unclamp sensor model, it features a built‑in PAL sensor to positively detect the unclamp endpoint, enabling seamless synchronization with workpiece lifters and high‑speed automation. Its short‑stroke (5/10 mm) design delivers reliable clamping force at 7 MPa, with sensors fully enclosed to prevent chip buildup and ensure stable operation in harsh machining environments.
Main Models: CTM-05LN CTM-05RN CTM-06LN CTM-06RN CTM-10LN CTM-10RN etc.
Pascal CTM‑N Product Introduction (7MPa Double‑Acting Compact Swing Clamp Cylinder, Unclamp Sensor Model)
Overview
The Pascal CTM‑N series is a compact, double‑acting hydraulic swing clamp designed for space‑constrained CNC fixtures and automated production lines. As an unclamp sensor model, it features a built‑in PAL sensor to positively detect the unclamp endpoint, enabling seamless synchronization with workpiece lifters and high‑speed automation. Its short‑stroke (5/10 mm) design delivers reliable clamping force at 7 MPa, with sensors fully enclosed to prevent chip buildup and ensure stable operation in harsh machining environments.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Compact Form Factor: Space‑saving footprint ideal for dense fixture layouts.
- Built‑In Unclamp Sensor: Enables precise unclamp detection, reducing false signals from external sensors.
- 90° Swing Motion: High repeatability (±0.5° positioning accuracy) for reliable workpiece engagementPascal Engineering.
- 7MPa Rated Pressure: Delivers strong clamping force in a short‑stroke (5/10 mm) packagePascal Engineering.
- Chlorine‑Resistant Seals: Withstands chlorine‑based cutting fluids for industrial durabilityPascal Engineering.
- Versatile Piping: Manifold or G‑port options for flexible installation; compatible with VCF flow control valvesPascal Engineering.
- Easy Mounting: Through‑hole (X‑X) for side/bottom mounting; pre‑tapped holes for clamp arm installationPascal Engineering.
