Japan Pascal Link clamp 7MPa Double acting Compact model CLM-N CLM03-LN/FN/RN
Key Specifications
- Driving mode: Hydraulic clamping, hydraulic unclamping
- Operating pressure: 0.5–7 MPa (rated), 10.5 MPa (burst)
- Clamping force (7 MPa): 3.2–16.6 kN
- Full stroke: 18.5–35 mm
- Clamping stroke: 16–32 mm
- Operating temperature: 0–70°C
- Hydraulic oil: ISO‑VG32 mineral oil (compatible with chlorine‑based cutting fluid)
Japan Pascal Link clamp 7MPa Double acting Compact model CLM-N CLM03-LN/FN/RN CLM04-LN/FN/RN CLM05-LN/FN/RN CLM06-LN/FN/RN CLM10-LN/FN/RN CLM16-LN/FN/RN
Product Introduction: Pascal CLM‑N Series Compact Link Clamp
Overview
CLM‑N is a 7MPa double‑acting compact link clamp from PASCAL Japan. Designed for narrow spaces, high‑density fixturing, and lightweight workholding, it features hydraulic clamping/unclamping and optional built‑in sensing for error prevention. Ideal for automated lines, precision machining, and rapid mold change.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Automotive precision machining: Engine components, transmission housings, chassis parts.
- Mold machining: Die steel, cavities, mold bases for rapid changeover.
- General machining: Hardware, sheet metal, small precision parts in unmanned lines.
- High‑density fixturing: Narrow spaces, multi‑fixture layouts for maximum space efficiency.
