Bosch Rexroth CDM1 heavy-duty tie-rod FANGU Long-stroke Hydraulic Cylinders Industrial Applications
The CDM1 Series is a heavy-duty tie-rod hydraulic cylinder from Bosch Rexroth, designed for high-load, long-stroke industrial applications. It adheres to ISO 6020/1 and VW 39 D 920 standards, delivering robust rigidity, stable performance, and easy maintenance.
Bosch Rexroth CDM1 Series Hydraulic Cylinders
The CDM1 Series is a heavy-duty tie-rod hydraulic cylinder from Bosch Rexroth, designed for high-load, long-stroke industrial applications. It adheres to ISO 6020/1 and VW 39 D 920 standards, delivering robust rigidity, stable performance, and easy maintenance. With a modular design and 9 mounting options, it excels in environments requiring precise motion control and durability.
Example models:
- CDM1ME5/63/28/200A2X/B11HHUMWW
- CDM1MF3/80/56/300A2X/B11HHUMWW
- CDM1MT4/50/22/180A2X/B22HFDTWW
- CDM1MP5/100/45/400A2X/B11HHDMWW
- CDM1MT4/80/56/350A2X/B22CHUMWW
- CDM1MP5/125/70/500A2X/B11HFDTWW
- CDM1MF3/160/90/600A2X/B22HHDMWW
- CDM1ME5/100/56/450A2X/B11CHUMWW
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
1. Machine Tools
Precision fixture clamping, CNC slide positioning, automatic tool changers, and indexing table stroke control. Delivers high repeatability for accurate machining processes.
2. Presses
Die opening/closing stroke control, stamping force closed-loop adjustment, bending machine ram positioning, and mold cushion control. Suppresses impact and ensures stable forming pressure.
3. Injection Molding
Mold clamping stroke control, core-pulling displacement feedback, ejector mechanism adjustment, and high-cycle mold opening/closing. Guarancies consistent molding precision and long service life.
4. Metallurgy Equipment
Roll gap fine adjustment, continuous caster vibration control, furnace door positioning, and smelting line linear drives. Operates reliably in high-temperature, dusty environments.
5. Steel Mills
Billet pushing stroke control, roller spacing adjustment, furnace gate positioning, and steel conveying directional switching. Resists fatigue under extreme long-term loads.
6. Material Handling
Lifting platform control, conveyor steering positioning, automatic loading/unloading, and heavy workpiece transfer. Simplifies system alignment and boosts automation efficiency.
7. Construction Equipment
Crane outrigger extension, boom positioning, mechanical arm angle feedback, and outdoor engineering drives. Withstands wide temperature differences and harsh outdoor conditions.
8. Heavy Industrial Environments
Mining equipment control, marine hydraulic linear drives, power station valve stroke adjustment, and automated production line position feedback. Runs 24/7 under high load, vibration, and temperature extremes.
