Bosch Rexroth SCT3 Series – Double-Rod Hydraulic Cylinders SCT3ME5/50/36/200D3X/B11HHUMWW SCT3ME5/63/36/300D3X/B11HHUMWW SCT3ME5/80/56/400D3X/B11HHUMWW
Bosch Rexroth SCT3 Series – Double-Rod Hydraulic Cylinders with Integrated Position Measurement
Product Overview
The Rexroth SCT3 (Component Series 3X) is a double‑rod, tie‑rod hydraulic cylinder with a fully integrated linear position transducer (LDT). Built on the robust CDT3/CGT3 platform, it combines the symmetric motion of a double‑rod design with precise, real‑time position feedback for closed‑loop control systems. It is the instrumented, double‑acting counterpart to the single‑rod CST3 series.
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
Integrated Position Sensing
- Non‑contact, wear‑free magnetostrictive transducer fully housed within the rod.
- High accuracy & repeatability for precision closed‑loop motion controlRexroth.
- Eliminates external mounting, alignment, and protection of separate sensors.
- Symmetric performance: Equal force/speed on extend/retract with dual‑sided feedback.
Modular & Service‑Friendly Design
- Shared 3X platform with CDT3/CGT3 for familiar maintenance and parts interchangeability.
- Patented safety bleeding device for quick, safe air purging.
- Freely rotatable port positions (head/cap) for flexible installation.
- Integrated guide bushing simplifies seal replacement.
Flexible Cushioning
- U: No cushion
- D: Self‑adjusting cushion (auto‑optimizes for all speeds)
- Z: Manual adjustable cushion (fine‑tune deceleration)
- Closed‑loop hydraulic systems requiring precision position control
- Synchronized multi‑axis machinery (presses, injection molding)
- Automation & material handling (positioning tables, gantries)
- Machine tools (spindle balancing, accurate feed control)
- Test rigs & simulation equipment
- Die‑casting & forming machines
