Bosch Rexroth CSG Heavy-duty Tie-rod Hydraulic Cylinders High Precision for Industrial Applications

Example Models:

CSG125MT4/70/500Z/B22HFDTWW
CSG125MP5/70/550Z/B11CHUMWW
CSG160ME5/90/600Z/B22HHDMWW
CSG160MF3/90/700Z/B11HFUMWW
CSG200MT4/110/800Z/B22HFDTWW
CSG200MP5/140/900Z/B11HHDMWW
CSG50-MS2-150/B11HHDMWW
CSG71-MT4-250/B11HFUMWW

Bosch Rexroth CSG Series Hydraulic Cylinders

Product Overview

The CSG series by Bosch Rexroth consists of high-performance tie-rod hydraulic cylinders engineered for heavy-duty industrial applications, including machine tools, automation systems, and general mechanical equipment. Designed for reliability and precision, they deliver stable force output across diverse operating conditions.

Example Models:

CSG125MT4/70/500Z/B22HFDTWW
CSG125MP5/70/550Z/B11CHUMWW
CSG160ME5/90/600Z/B22HHDMWW
CSG160MF3/90/700Z/B11HFUMWW
CSG200MT4/110/800Z/B22HFDTWW
CSG200MP5/140/900Z/B11HHDMWW
CSG50-MS2-150/B11HHDMWW
CSG71-MT4-250/B11HFUMWW

Q: What’s the MOQ of customized tie-rod cylinder?

A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.

Q:What’s the lead time of customized tie-rod cylinder?

A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.

Q: Are you the manufacturer of hydrualic cylinder?

A: Sure, we are the manufacutuer and trading of hydraulic cylinder.

Q: What is the difference between double acting and single acting cylinders?own controlled by the pump or the valve or is it only one speed?

A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through

a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.

Q: I have a drawing, could you customized cylinder as my drawing?

A: Sure. Show us the drawing, we will quote for you soonest.

Q: Could you make the cylinder which is not on the above data sheet?

A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.

Modular Tie-Rod Structure

High-rigidity four-rod assembly simplifies maintenance, enabling quick seal replacement and component interchangeability. Ideal for space-constrained layoutsBosch Rexroth.
High Force Density

Optimized cylinder geometry delivers exceptional pulling/pushing forces (up to ~420 kN at 250 bar) for heavy loads, with consistent force retention under dynamic conditions.
Precision & Repeatability

Precision machining ensures <0.05 mm positioning repeatability, supported by optional end-position damping (self-adjusting/adjustable) for smooth operationBosch Rexroth.
Versatile Mounting Flexibility

13+ mounting configurations (ME5/MF3, MP1/MP3/MP5, MS2, MT4, MX) adapt to diverse installation needs, with freely selectable port positions for easy integrationBosch Rexroth.
Robust Environmental Resistance

Dust-proof and chip-resistant sealing systems (IP67/IP68) withstand harsh machining environments, while corrosion-resistant finishes extend service lifeBosch Rexroth.
Servo-Ready Compatibility
Low-friction seal packages and smooth piston movement support closed-loop control, making CSG suitable for servo-hydraulic systems requiring high dynamic response.
