Japan Yuken CG FANGU OEM Equal-Speed Heavy-Duty Double-acting Differential Hydraulic Cylinders for Metal Forging＆Injection Molding
Example Models:
- CG-SD80/45-400B-ABD-35
- CG-SD125/70-600B-ABD-25
- CG-TA50/28-300B-ABD-25
- CG-TC80/45-500N-ABD-35
- CG-TA140/80-800B-ABD-25
- CG-LB63/36-380N-ABD-35
- CG-LA100/55-500B-ABD-25
- CG-CA100/55-550B-ABD-25
- CG-CB160/90-900B-ABD-35
Yuken CG Series Equal-Speed Heavy-Duty Hydraulic Cylinders
Product Introduction
The Yuken CG Series is a line of heavy-duty, double-acting hydraulic cylinders designed for equal-speed extension and retraction. As the “equal-speed counterpart” to the differential CD Series, the CG Series delivers balanced linear motion, making it ideal for applications requiring precise, synchronous movement without speed differential.
Built to meet ISO and JIS standards, the CG Series features a robust four-tie-rod structure, high rigidity, and exceptional stability—suitable for harsh, high-load industrial environments. It is widely applied in heavy machinery, metal forging, injection molding, and large-scale automation fixtures.
Example Models:
- CG-SD80/45-400B-ABD-35
- CG-SD125/70-600B-ABD-25
- CG-TA50/28-300B-ABD-25
- CG-TC80/45-500N-ABD-35
- CG-TA140/80-800B-ABD-25
- CG-LB63/36-380N-ABD-35
- CG-LA100/55-500B-ABD-25
- CG-CA100/55-550B-ABD-25
- CG-CB160/90-900B-ABD-35
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
Features
- Equal-Speed Performance: Balanced extend/retract speeds eliminate differential motion, ensuring precise positioning and consistent cycle times.
- Heavy-Duty Durability: Induction-hardened, hard-chrome plated piston rod for superior wear and buckling resistance.
- High Rigidity: Four-tie-rod structure for stable operation under high loads and frequent cycles.
- Versatile Mounting: Wide range of end mounts for flexible integration into diverse machinery.
- Low Leakage: Precision-machined cylinder tube and premium seal groups (NBR/FKM) for long-term reliability.
- Easy Maintenance: Modular design simplifies seal replacement and component servicing.
Typical Applications
- Heavy-duty presses and stamping equipment
- Injection molding machine clamping and ejection systems
- Large CNC machining centers and precision fixtures
- Metallurgical and mining machinery linear drives
- High-load, high-precision automation production lines
