Bosch Rexroth CSH1 FANGU OEM CSH1ME5 CSH1MF3 CSH1MF3 for Injection Molding and Metallurgy
Rexroth CSH1 Series heavy-duty welded hydraulic cylinders integrate built-in magnetostrictive position feedback sensors, realizing high-precision closed-loop stroke control. Adopting robust mill-type welded structure, fully compliant with ISO 3320 standards, it delivers ultra-high rigidity, strong impact & lateral load resistance, stable long-cycle operation and precise real-time displacement monitoring.
Bosch Rexroth CSH1 Series Hydraulic Cylinders
Rexroth CSH1 Series heavy-duty welded hydraulic cylinders integrate built-in magnetostrictive position feedback sensors, realizing high-precision closed-loop stroke control. Adopting robust mill-type welded structure, fully compliant with ISO 3320 standards, it delivers ultra-high rigidity, strong impact & lateral load resistance, stable long-cycle operation and precise real-time displacement monitoring. Widely used in intelligent heavy-duty hydraulic systems requiring accurate position closed-loop control.
Example models:
- CSH1ME5/50/22/180A10/XXCASX B11HFUMWW
- CSH1MF3/63/28/220A10/XXCASX B22HFDTWW
- CSH1MT4/80/36/320A10/XXCASX B11HHDMWW
- CSH1MP5/100/56/400A10/XXCASX B22HFUMWW
- CSH1MT4/125/70/600A10/XXCASX B22HFDTWW
- CSH1MF3/160/90/750A10/XXCASX B11HHDMWW
- CSH1MP5/200/110/900A10/XXCASX B22HFUMWW
- CSH1ME5/250/140/1000A10/XXCASX B11HFDTWW
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Rated Working Pressure: 250 bar, Test Pressure: 375 bar
- Structure: Double-acting single-rod heavy welded cylinder, integrated magnetostrictive position sensor
- Bore Diameter Range: 40 ~ 320 mm
- Rod Diameter Range: 22 ~ 220 mm
- Maximum Custom Stroke: Up to 6000 mm
- Signal Output: Analog 4–20mA / Digital Profinet / IO-Link bus communication
- Temperature Range: -20℃ ~ +120℃
- Mounting Options: MF3 Front Flange, MP5 Rear Flange, MT4 Trunnion, ME5 Rear Clevis, Foot Mount, Side Lug
- Seals: Low-friction NBR standard seals; High-temperature FKM seals optional
- Optional Configurations: Adjustable end cushions, travel limit switches, anti-corrosion rod treatment, special oil port layout
- Built-in non-contact magnetostrictive sensor, no external installation, high positioning accuracy & repeatability
- Integrated heavy-duty welded body, excellent bending & shock resistance, suitable for ultra-long stroke heavy load
- Full digital bus communication, seamless docking with PLC closed-loop motion control system
- Induction hardened & hard chrome-plated piston rod, outstanding wear resistance and corrosion resistance
- Modular seal & guide structure, easy disassembly, maintenance and low whole-life operation cost
- Excellent anti-buckling design, stable operation under high-frequency reciprocating and complex eccentric loads
- Compatible with mineral oil, water-glycol, phosphate ester and multiple special hydraulic media
