YUKEN CJT210C Compact Tie-rod Double-acting Hydraulic Cylinders Stable Cushion Performance
Example Models:
- CJT210C-FA40C180B-ABD-20
- CJT210C-FB50C300N-ABD-20
- CJT210C-FA80C450B-ABD-20
- CJT210C-FB125C700B-ABD-20
- CJT210C-CA40C220B-ABD-20
- CJT210C-CB63C400N-ABD-20
- CJT210C-CA100C550B-ABD-20
- CJT210C-CB160B900B-ABD-20
YUKEN CJT210C Series Compact Hydraulic Cylinders
Product Introduction
CJT210C Series is YUKEN 21 MPa compact short-length tie-rod double-acting hydraulic cylinders, upgraded optimized structure based on standard CJT210. It features shorter overall length, space-saving installation, stable cushion performance and high rigidity. Fully compliant with JIS B8354 & ISO standards, specially designed for narrow-space heavy-load machinery, precision fixtures and compact automation equipment.
Example Models:
- CJT210C-FA40C180B-ABD-20
- CJT210C-FB50C300N-ABD-20
- CJT210C-FA80C450B-ABD-20
- CJT210C-FB125C700B-ABD-20
- CJT210C-CA40C220B-ABD-20
- CJT210C-CB63C400N-ABD-20
- CJT210C-CA100C550B-ABD-20
- CJT210C-CB160B900B-ABD-20
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
Key Features
- Ultra-compact overall dimension: Shorter total length than regular CJT210, greatly saves equipment installation space
- Optimized integrated cushion structure: Built-in cushion ring & direct check valve, stable impact absorption, low vibration, no exposed external parts
- Induction hardened + hard chrome-plated piston rod, excellent buckling resistance, wear resistance and long service life
- High-rigidity tie-rod structure, easy disassembly, seal replacement and daily maintenance
- Modular seal packages: NBR standard, FKM high-temperature & corrosion-resistant optional
- Compatible with slide-type proximity switches, easy to realize automatic position feedback control
- Non-interchangeable internal parts with old CJT210 standard cylinders
Typical Applications
- Compact CNC machine tool fixtures
- Injection molding machine narrow-space clamping units
- Mini heavy-duty hydraulic presses
- Automatic assembly & conveying compact equipment
- Packaging, metallurgy small-space linear drive mechanisms
