VEKTEK Type G Double-Acting Bottom Flange Mount compact Block-style Standard Side Port Linear Cylinders
Standard Model List
- L2-1121-00
- L2-1121-01
- L2-1121-02
- L2-1121-03
- L2-1121-04
- L2-1121-05
- L2-1121-06
- L2-1121-07
- L2-1121-08
- L2-1121-09
VEKTEK Type G Double-Acting, Bottom Flange Mount, Standard Side Port Linear Cylinders
General Overview
VEKTEK Type G linear cylinders are compact block-style double-acting hydraulic cylinders designed for machine tool fixtures. With bottom plate mounting and standard side hydraulic ports, the piston rod extends and retracts under bidirectional hydraulic control. They deliver straight-line push / pull force for workpiece clamping, ejection, positioning and auxiliary actuation on machining jigs. The rectangular block structure allows dense arrangement on fixture base plates.
Typical Applications:
- Linear workpiece clamping and positioning on CNC fixtures
- Workpiece ejection and auxiliary pushing mechanisms
- Milling, drilling and tapping clamping jigs
- Automated assembly tooling
- Light to medium load linear actuation systems
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Double-Acting Operation: Hydraulic pressure drives both extend and retract strokes; precise push and pull force control.
- Bottom Plate Mounting: Rectangular block body with mounting holes on the bottom surface, easy surface installation on fixture plates.
- Standard Side Hydraulic Ports: Two threaded ports located on the side face for convenient hose connection.
- Modular Block Design: Compact square housing, suitable for tight fixture layouts.
- Multiple stroke options covered by complete model lineup.
- Hardened piston rod and durable sealing system for long-cycle industrial operation.
- Optional proximity sensor grooves for stroke position feedback.
- Double-acting design provides controllable force in both extending and retracting directions.
- Compact block construction saves fixture installation space and enables multi-cylinder dense layout.
- Bottom plate mounting ensures stable positioning and uniform load distribution.
- Standard side ports simplify hydraulic piping arrangement.
- Rich stroke options meet diversified linear actuation requirements.
- High rigidity block body resists side loads during clamping and positioning.
