Parker CXP Series Compact Hydraulic Cylinders
Series Overview
The Parker CXP Series are high-performance, compact hydraulic cylinders designed for space-constrained industrial automation and machinery applications. Engineered for high power density, these cylinders deliver robust force and reliable operation in a minimized envelope, making them ideal for installations where traditional cylinders cannot fit.
- Series Type: Compact, welded-construction, double-acting hydraulic cylinders
- Core Design: Optimized for small footprint, lightweight, and high-pressure performance
- Standards: Compliant with ISO 6020/2 and NFPA industrial dimensions
- Pressure Rating: 210 bar (3045 PSI) – standard operating pressure
- Fluid Compatibility: Mineral oil, synthetic hydraulic fluids (HFC, HFD)
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Ultra-Compact Design: Significantly shorter length and smaller diameter than standard industrial cylinders, ideal for tight machine layouts.
- High Power Density: Delivers full rated force (up to 120 kN) despite compact dimensions.
- Durable Welded Construction: One-piece, high-strength steel barrel with welded end caps for maximum rigidity and leak resistance.
- Hard Chrome-Plated Piston Rod: Precision-ground, high-tensile steel rod with hard chrome plating for exceptional wear, corrosion, and scratch resistance.
- Advanced Piston Sealing System: Parker's proprietary multi-lip seal design ensures zero leakage, low friction, and extended service life.
- Integrated Sensor Compatibility: Precisely machined grooves for easy mounting of proximity switches or magnetic position sensors.
- Cushion Options: Available with fixed or adjustable end-stroke cushions to absorb kinetic energy and reduce noise at stroke ends.
- Wide Temperature Range: Operates reliably from -20°C to +105°C (-4°F to +221°F).
- Maintenance-Free: Robust seal design minimizes wear, reducing downtime and service requirements.
- Versatile Mounting: Multiple standard mounting styles for easy integration into diverse machine frames.
The CXP Series excels in applications prioritizing space efficiency and precision:
- Industrial Automation: Compact assembly lines, pick-and-place machines, small presses
- Robotics: Wrist and joint actuators, end-of-arm tooling
- Medical & Laboratory Equipment: Precision positioning, clamping mechanisms
- Packaging Machinery: Forming, sealing, and cutting actuators
- Solar Tracking Systems: Lightweight, high-force linear actuators
- Material Handling: Compact lifts, tilters, and clamps
- Specialty Machinery: Any application with strict space limitations
