German HEISS Hydraulic Compact Cylinder HKZ 160 High Load Limited Installation 160 Bar
Example Models:
- HKZ 160-A-25/12/20-108
- HKZ 160-A-32/20/25-112X
- HKZ 160-A-40/25/30-116
- HKZ 160-A-50/32/25-120.X6
- HKZ 160-A-63/40/40-124
- HKZ 160-A-80/50/50-130.XW
- HKZ 160-B-32/16/15-110
- HKZ 160-B-40/20/20-112
- HKZ 160-B-50/25/30-116.XS
- HKZ 160-B-63/32/40-120
- HKZ 160-B-80/40/50-124
HEISS Hydraulic Compact Cylinder HKZ 160
Product Overview
The HKZ 160 is a high-performance compact hydraulic cylinder independently developed and manufactured by HEISS, designed for limited installation space and high-load industrial clamping and linear driving scenarios. As a core product of HEISS compact cylinder series, it features a ultra-compact integrated round structure, high structural rigidity and outstanding pressure resistance, breaking the size limitation of traditional standard cylinders while maintaining stable heavy-load output performance. Rated for a maximum operating pressure of 160 bar, this cylinder realizes high-efficiency linear hydraulic transmission with minimal installation dimensions, perfectly matching modern compact automated equipment, fixture clamping systems and precision mechanical driving units .
Adopting standardized ISO and DIN seal groove specifications, the HKZ 160 series features a service-friendly sealing structure, convenient maintenance and long-term operational stability. It supports multiple installation forms and customized configurations, covering conventional mineral hydraulic oil and special water-based hydraulic medium working conditions, with strong environmental adaptability and universal industrial compatibility .
Q: What’s the MOQ of customized tie-rod cylinder?
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
Q:What’s the lead time of customized tie-rod cylinder?
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
Q: Are you the manufacturer of hydrualic cylinder?
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
Q: What is the difference between double acting and single acting cylinders?own controlled by the pump or the valve or is it only one speed?
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
Q: I have a drawing, could you customized cylinder as my drawing?
A: Sure. Show us the drawing, we will quote for you soonest.
Q: Could you make the cylinder which is not on the above data sheet?
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
All technical indicators of HEISS HKZ 160 compact hydraulic cylinders comply with international hydraulic industry standards, with standardized parameters and diversified optional configurations to meet differentiated working condition requirements:
-
Rated Maximum Operating Pressure: 160 bar, stable heavy-load output, suitable for high-pressure clamping and driving operations
-
Standard Piston Sizes: Equipped with 6 standard piston diameter specifications, covering multi-tonnage load ranges for flexible model selection
-
Maximum Piston Travel Speed: 0.5 m/s for standard continuous operation; customized high-speed versions are available on request
-
Operating Temperature Range: Standard sealing kit adapts to -20°C to +80°C; X6 high and low temperature resistant sealing configuration supports extreme temperature working conditions
-
Standard Medium Adaptation: Applicable to conventional mineral hydraulic oil (HL/HLP series); optional water-hydraulic corrosion-resistant version for special medium scenarios
-
Seal Standard: Seal grooves strictly comply with ISO 5597/1 and DIN ISO 7425/1 standards, ensuring precise fitting and zero leakage performance
-
Hydraulic Port Layout: Front and rear end face oil port design for retraction and extension, with simple pipeline arrangement and convenient installation
Ultra-Compact Integrated Structure
Different from bulky standard hydraulic cylinders, the HKZ 160 adopts an optimized one-piece round compact structure, which greatly reduces overall installation space while ensuring high structural rigidity. It solves the installation pain points of traditional cylinders in narrow-space equipment, and is the preferred power component for miniaturized and integrated automated machinery.
Easy Maintenance & High Sealing Reliability
The series adopts a humanized separable sealing assembly design with standardized seal specifications. The sealing components are easy to disassemble, replace and maintain, effectively reducing later operation and maintenance costs. The high-precision matching sealing system ensures no internal or external leakage under 160 bar long-cycle operation, maintaining stable clamping and driving accuracy .
Diversified Installation & Strong Compatibility
HKZ 160 supports multiple standard installation methods, including flange mounting, thread mounting and customized connection structures, adapting to various equipment assembly requirements. The series features high versatility of accessories and interfaces, which can be seamlessly matched with HEISS supporting hydraulic systems and mainstream domestic and foreign hydraulic equipment.
Customized Special Versions
On the basis of standard models, HKZ 160 provides multiple customized solutions: water-based hydraulic medium anti-corrosion version, extreme temperature resistant sealing version, high-speed operation version and ATEX explosion-proof certified version, which can meet the harsh working conditions of metallurgy, chemical industry, food processing and explosion-proof workshops .
