Parker SA Series Single Acting Telescopic Hydraulic Cylinders
Parker SA Series are heavy-duty, single-acting telescopic hydraulic cylinders designed for long-stroke, space-constrained mobile and industrial applications. Built for durability and high performance, they operate at 13.8 MPa (2000 psi) and deliver reliable extension via hydraulic pressure, with retraction driven by external forces or gravity.
Example models:
- S63DC-101-120.00
- S80DC-101-156.00
- S100DC-101-200.00
- S63LB-101-100.00
- S80FC-101-140.00
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Series: SA (Single Acting Telescopic)
- Design Pressure: 13.8 MPa (2000 psi)
- Construction: Steel (1026/A36), welded sleeve overlapsParkerGB
- Bore Sizes: 3.75" to 16.50" (95 mm to 419 mm)
- Max Stroke: Up to 500" (12,700 mm)
- Operating Temp: -40°F to 275°F (-40°C to 135°C)
- Fluid: Standard hydraulic oils
- Warranty: 18 months
- Catalog: HY18-0032
- Long Sleeve Overlap: Improves stability, reduces side loading, and extends service life.
- Threaded Steel Stop Rings: Ensures reliable, precise stopping and simplifies maintenance.
- Bleeder-less Design: Eliminates time-consuming and costly air-bleeding procedures.
- External Packing Nuts: Provides extra structural support for the cylinder tube.
- High-Performance Seals: Polyurethane rod wipers resist high temperatures and extrusion.
- Glass-Filled Bearings: Snap-in design absorbs contaminants without damaging cylinder walls.
- Nylon-Tipped Set Screws: Prevents packing nuts from loosening during operation.
- 100% Factory Tested: Every unit is tested for leak-free operation and performance.
