Parker HV2 Series Heavy-Duty Hydraulic Cylinders
Parker Miller HV2 Series is a heavy-duty, NFPA-compliant industrial hydraulic cylinder line, designed for extreme-duty, high-temperature, and long-service-life applications.
- HV284B2B-4.00-24.000-N11T-0
- HV261B2B-6.00-36.000-H13
- HV2-KR125-1000
- HV2-KR225-1000
- HV2-KB300-1000
- HV2-KB500-1000
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Standard: ANSI/NFPA T3.6.7R2-1996
- Nominal Pressure: 3000 psi (210 bar)
- Bore Sizes: 1.50" – 20.00" (38.1 mm – 508 mm)
- Piston Rod Diameters: 0.625" – 4.000"
- Standard Fluid: Hydraulic oil
- Temperature Range:
- Standard: -10°F to +165°F (-23°C to +74°C)
- Fluorocarbon seals: -10°F to +250°F (-23°C to +121°C)
- High-temp (limited life): up to +400°F (+204°C)
- Proof Pressure: 4500 psi (1.5 × working pressure)
- Burst Pressure: 9000 psi min (3 × working pressure)
- Stroke: Custom to any practical length
- Style: Tie-rod, square head design
- Tie Rods: SAE Grade 5 or better high-strength steel
- Gland: Externally removable bolted bushing assembly
- Piston:
- Standard: Nut-retained (lip seal or O-ring)
- Hi-Load piston standard on 7" & 8" bores
- Piston-rod connection: Threaded + anaerobic adhesive; pinned for high temp
- Piston Rod: Hard chrome-plated high-strength steel
- Seal System:
- Standard: Polyurethane seals for dry-rod performance
- Optional: Fluorocarbon (Viton) for high temp / fire-resistant fluids
