Parker LE Series Hydraulic Cylinders
Product Overview
The Parker LE Series is an economical, light-to-medium duty, tie-rod construction hydraulic cylinder line, serving as a robust upgrade or complement to the LA Series. Engineered for double-acting operation, it delivers reliable linear motion for general industrial applications, balancing cost-efficiency with enhanced durability and performance compared to lighter-duty alternatives.
Example Models:
- LE25C050A0A1
- LE32C100A0A1
- LE40C150A0A1
- LE50C200A0A1
- LE63C250A0A1
- LE80C300A0A1
- LE100C400A0A1
- LE125C500A0A1
- LE50B200A1A1 (Rear flange, cap-end cushion)
- LE63D250A3B1 (Front trunnion, double cushion, BSPP)
- LE80J300A0C1 (Clevis, SAE ports)
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Heavy-Duty Tie-Rod Design: Four high-tensile tie rods secure cylinder components, ensuring structural rigidity under moderate loads and enabling straightforward disassembly for maintenance, seal replacement, or repairs.
- Enhanced Performance Rating: Capable of operating at a nominal pressure of up to 210 bar (3000 psi), suitable for more demanding cycles than the LA Series.
- Premium Componentry:
- Piston Rod: Case-hardened, hard-chrome plated steel for exceptional wear resistance, corrosion protection, and prolonged seal life.
- Cylinder Tube: Precision-honed and polished internal surface to ensure smooth piston travel and optimal seal performance.
- Parker High-Performance Seals: Integrated low-friction, long-life seal system designed to minimize leakage, reduce starting friction, and ensure consistent operation.
- Versatile & Interchangeable: Complies with NFPA/ANSI standard dimensions, ensuring broad compatibility and easy interchangeability with other standard tie-rod cylinders.
- Flexible Configuration: Offers a wide selection of mounting styles, port types, rod options, and optional cushions to fit diverse application requirements.
- Cost-Effective Reliability: Provides Parker's quality assurance at a competitive price point, ideal for budget-conscious projects requiring dependable performance.
- Series Designation: LE (Economical Medium-Duty Tie-Rod Hydraulic Cylinder)
- Operation: Double-Acting (Standard)
- Maximum Operating Pressure: Up to 210 bar (3000 psi) (varies by bore size)
- Bore Sizes (Metric & Imperial):
- Metric: 25 mm, 32 mm, 40 mm, 50 mm, 63 mm, 80 mm, 100 mm, 125 mm
- Imperial: 1.5", 2", 2.5", 3", 3.5", 4", 5", 6"
- Stroke Lengths: Customizable from 25 mm (1") up to 3000 mm (118")
- Operating Temperature Range: Standard: -20°C to +80°C (-4°F to +176°F)
- Compatible Fluids: Mineral oil, synthetic fire-resistant fluids (HFC, HFD)
- Mounting Configurations: Multiple standard NFPA styles (Foot, Front Flange, Rear Flange, Front Trunnion, Rear Trunnion, Clevis, Side Lug, etc.)
- Port Thread Options: Standard NPT; optional BSPP, SAE
- Cushion Options: No cushion (standard), cap-end cushion, head-end cushion, double cushions (both ends)
