Parker HTR Series Helical Hydraulic Rotary Actuators
Product Introduction
The Parker HTR Series is a high-performance helical hydraulic rotary actuator, designed to deliver high torque in a compact, space‑saving form factor. It converts hydraulic pressure into precise rotary motion, widely used for clamping, positioning, rotating, and turning applications in machine tools, automation fixtures, and industrial machinery.
Example Models:
- HTR5 180 3 V A 1 J
- HTR150 360 0 – B 2 –
- HTR.9 90 1 – A 1 –
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Helical gear design for high torque density and smooth rotation
- Compact structure, ideal for installation in limited spaces
- Wide rotation angles: typically 90°, 180°, 270°, 360° and custom angles
- High rigidity and strong anti‑impact performance
- Precise positioning with stable rotation and low backlash
- Hardened components for long service life and wear resistance
- Leak‑proof sealing system suitable for continuous industrial operation
- Flexible mounting options for easy integration into various equipment
- Operating pressure: Up to 210 bar (3000 psi)
- Torque range: Covers small to medium‑high torque models
- Rotation angle: 90° / 180° / 270° / 360° (customizable)
- Medium: Mineral oil and standard hydraulic fluids
- Temperature range: Standard −20°C to +80°C
- Type: Single‑ or double‑acting rotary actuation
