Prince 2500 PSI Tie‑Rod 2 Inch Bore Medium‑duty Double‑acting Cylinders Side Port Configuration
Example Models:
- W200040-S
- W200060-S
- W200080-S
- V200080-S
- W200100-S
- W200120-S
- W200160-S
- W200360-S
Prince 2500 PSI Tie‑Rod Cylinders Product Introduction
Overview
Prince 2500 PSI Tie‑Rod Hydraulic Cylinders are medium‑duty double‑acting tie‑rod style cylinders engineered by Prince Manufacturing for reliable industrial and mobile hydraulic applications. Rated for a continuous working pressure of 2500 PSI, these cylinders adopt a bolt‑together tie‑rod construction, delivering excellent stability, easy maintenance and cost‑effective performance for general‑purpose hydraulic systems. Designed for moderate‑load scenarios, they are widely used in agricultural equipment, material handling machinery, factory automation and light‑duty construction machinery.
Technical Specifications
- Rated Continuous Pressure: 2500 PSI
- Bore Range: 2″ – 5″ standard sizes
- Stroke Range: 4″ – 48″ customizable
- Mounting Style: Clevis‑to‑Clevis (standard)
- Port Type: NPTF / SAE O‑ring ports
- Construction: Double‑acting, tie‑rod bolt‑together design
- Standard Finish: Gloss black anti‑corrosive paint
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Heavy‑Duty Tie‑Rod Structure
High‑strength steel tie‑rods secure the honed steel tube, end caps and piston assembly together. This bolt‑on design enables full disassembly for inspection, seal replacement and component maintenance without special welding tools.
- Precision‑Finished Piston Rod
Ground, polished and hard‑chrome‑plated piston rod offers outstanding wear resistance, corrosion resistance and smooth linear motion, extending service life in dusty and humid working environments.
- Premium Internal Components
Ductile iron piston and gland provide high impact resistance and structural rigidity; urethane U‑cup seals, metal‑encased wipers and O‑ring backup washers ensure leak‑free performance under 2500 PSI continuous pressure.
- Standard Clevis Mounting
Steel rod clevis and base clevis conform to ASAE industry standards, equipped with grease zerks for pivot lubrication, reducing pin friction and wear for long‑term operation.
- Standard Port Configuration
Side‑mounted NPTF or SAE O‑ring ports for flexible hydraulic line connection, compatible with mainstream hydraulic hoses and fittings.
- Strict Quality Assurance
Every cylinder is 100% pressure‑tested before delivery. Standard high‑gloss black anti‑corrosive paint finish protects against rust and environmental damage; individually bagged and boxed for safe transportation.
- Agricultural machinery: tractors, hay balers, small loaders
- Material handling equipment: conveyors, lifting platforms, stackers
- Light‑duty construction machinery and municipal equipment
- General industrial automation, hydraulic fixtures and OEM machinery systems
