Parker (TAIYO) PSR-1 / PSR-1A Series
Parker TAIYO PSR-1 (PSR-1A) Series is a 16 MPa compact hydraulic cylinder with built-in absolute position sensor, designed for precise position feedback in automation machinery. It shares identical mounting dimensions with the 160S-1 series, ensuring easy interchangeability.
Example models:
- PSR-1A 6 SD32 5
- PSR-1A 6 SD32 10
- PSR-1A 6 SD32 15
- PSR-1A 6 SD32 20
- PSR-1A 6 SD32 25
- PSR-1A 6 SD32 30
- PSR-1A 6 SD32 35
- PSR-1A 6 SD32 40
- PSR-1A 6 SD32 45
- PSR-1A 6 SD32 50
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Series: PSR-1, PSR-1A (Absolute type)
- Function: Double-acting, position-sensing compact hydraulic cylinder
- Design Pressure: 16 MPa (2320 psi)
- Proof Pressure: 24 MPa (3480 psi)
- Bore Sizes (Ø): 32, 40, 50, 63, 80, 100, 125 mm
- Standard Stroke: 5 to 50 mm (60 mm+ available on request)
- Rod End: Male thread (standard)
- Position Sensor: Built-in absolute magnetic encoder
- Sensor Power: 12–24 VDC
- Output Signal: Digital (parallel / serial) or analog (optional)
- Operating Temp: -10°C to +120°C
- Fluid: Mineral oil (ISO VG32–68)
- Mounting Interchangeability: Identical to 160S-1 series
- Built-in Absolute Position Sensor: No need for homing on power-up; retains position data.
- Compact & Space-Saving: Sensor integrated on head side; no increase in width.
- Strong Magnetic Field Resistance: Operates reliably where magnetic switches fail.
- High Precision: Standard resolution 0.1 mm (higher options available).
- Full Interchangeability: Direct replacement for 160S-1 cylinders without mechanical modification.
- Durable Construction: Robust steel body, hard chrome-plated rod, long-life HNBR seals.
