Parker SA Series Stainless Steel Pneumatic Cylinders
Parker SA Series are premium stainless steel pneumatic tie-rod cylinders, engineered for exceptional corrosion resistance and reliable performance in harsh, high-sanitary environments. Designed to NFPA standards, they are the ideal solution for applications requiring frequent chemical washdowns and sterile conditions.
Example Models:
- S63DC-101-120.00
- S85DC-66-190.00
- S85DC-66-235.00
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- All-Stainless Construction: Main body components (head, cap, tube, rod, tie-rods) manufactured from 303 & 304 stainless steel, providing superior resistance to chemicals, moisture, and oxidation (piston is aluminum).
- Non-Lube Service Rated: Operates efficiently without lubrication, minimizing maintenance and contamination risks.
- Hygienic Design: Smooth, crevice-free surfaces with stainless steel acorn nuts covering tie-rod threads to eliminate bacterial harborage points.
- High-Performance Sealing System:
- Pressure-energized lip rod seals that automatically compensate for wear.
- Aggressive rod wiper to clean contaminants and extend seal life.
- PTFE/graphite wear strips for minimal friction and maximum side-load resistance.
- Adjustable Captive Cushions: Precision, safe end-of-stroke speed control adjustable under pressure.
- Versatile Options: Available with optional piston bumper seals and magnetic pistons for position sensing.
- Standard: NFPA interchangeable
- Fluid Type: Compressed Air (Non-lubricated or lubricated)
- Operating Pressure: Up to 250 psi (17.2 bar)
- Bore Sizes: 1.13", 1.5", 2", 2.5", 3", 3.5", 4", 5", 6", 8"
- Temperature Range: -10°F to +165°F (-23°C to +74°C)
- Action: Double-acting (standard)
- Mounting Styles: 8 standard NFPA mounting configurations
- Port Connections: Standard NPT (other options available)
