Parker CXP Series Compact Hydraulic Cylinders
Product Overview
The Parker CXP Series is a line of high-performance, compact hydraulic cylinders designed for applications where space is limited but precision, power, and reliability are critical. Engineered with a minimized envelope and lightweight construction, the CXP Series delivers exceptional force density and seamless integration into modern automated machinery.
Example models:
- CXP25JJ12M50C11
- CXP25JJ12M100C11
- CXP32JJ16M100C11
- CXP32C16M50C11
- CXP40C22M100C11
- CXP40D22M150C11
- CXP40SB22M200C11
- CXP50JJ28M150C11
- CXP50JJ28M200C11
- CXP50C28M100C11
- CXP63JJ36M150C11
- CXP63JJ36M200C11
- CXP63JJ36M300C11
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
A: Sure. Show us the drawing, we will quote for you soonest.
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
- Ultra-Compact Design: Smallest footprint and lightweight profile to save valuable installation space.
- High Force Output: Robust construction maintains high-pressure performance despite reduced size.
- Precision & Durability: Built with high-strength materials and precision machining for long service life under cyclic loads.
- Low-Friction Sealing: Advanced seal technology minimizes internal friction, ensuring smooth, responsive movement and long seal life.
- Sensor Integration: Pre-designed grooves and interfaces for easy integration of proximity switches or position sensors.
- Versatile Mounting: Multiple standard mounting options to adapt to various machine designs.
- Customization: Flexible modular design for tailored bore sizes, strokes, and options.
- Design: Double-acting, single piston-rod
- Rated Pressure: Up to 210 bar (3000 psi)
- Bore Sizes (mm): 25, 32, 40, 50, 63
- Rod Diameters (mm): Standard and heavy-duty options per bore
- Stroke Lengths: Customizable from 25mm up to 500mm+
- Standard Mountings:
- Front Flange (JJ)
- Rear Flange (HH)
- Foot Mount (C)
- Trunnion (D)
- Clevis (SB)
- Fluid Compatibility: Mineral oils, synthetic fluids, and biodegradable fluids
- Temperature Range: -20°C to +100°C
- Materials:
- Barrel: High-strength steel, honed
- Piston Rod: Hard-chrome plated steel
- Pistons: Ductile iron or aluminum
- Seals: Nitrile (NBR) standard; Fluorocarbon (FKM) optional
