Original German HEISS Booster Pneumatic-hydraulic Cylinder PHU Series Enger-saving High-pressure
Example Models:
- PHU 80/20-80.X6
- PHU 80/28-100.X11
- PHU 100/25-90.X10
- PHU 100/36-120.X7
- PHU 100/50-150.X3
- PHU 125/32-100.X6
- PHU 125/45-140.X11
- PHU 160/80-180.X10
- PHU 200/50-150
- PHU 200/100-200.X7
- PHU 250/63-180
- PHU 250/125-220.X0
HEISS Booster Cylinder PHU Series
Product Overview
The PHU Series is a professional pneumatic-hydraulic booster cylinder independently developed and manufactured by HEISS, serving as an energy-saving high-pressure power unit for industrial clamping, pressing and forming systems. Different from conventional pure hydraulic cylinders that rely on hydraulic pump stations, the PHU booster cylinder adopts air-driven hydraulic boosting principle, converting standard low pneumatic pressure into ultra-high hydraulic pressure through precise area ratio amplification. It eliminates the need for complex hydraulic pump stations, cooling systems and circulating pipelines, realizing high-pressure output with simpler structure, lower energy consumption and smaller installation space.
With a rugged integrated all-steel structure and standard DIN/ISO sealing specifications, the PHU series features stable boosting performance, zero leakage and strong fatigue resistance. It supports multiple standard amplification ratios and displacement volumes, covering low, medium and high-pressure working ranges. It is the ideal replacement for traditional hydraulic systems in light and medium heavy-load automation scenarios, widely used in fixture clamping, mold locking, precision pressing and mechanical positioning.
Q: What’s the MOQ of customized tie-rod cylinder?
A: Depends on the style of tie-rod. We would like to cast and forge once the quantity above 100 pcs.
Q:What’s the lead time of customized tie-rod cylinder?
A: Well, it depends on the quantity and style of hydrualic cylinders, at least 60 days if we make casting and forging, at least 35 days by maching.
Q: Are you the manufacturer of hydrualic cylinder?
A: Sure, we are the manufacutuer and trading of hydraulic cylinder.
Q: What is the difference between double acting and single acting cylinders?own controlled by the pump or the valve or is it only one speed?
A: Double-Acting-have a port at each end, supplied with hydraulic fluid for both the retraction and extension. Single-Acting-hydraulic fluid enters through
a port at one end of the cylinder, which extends the rod by means of area difference. An external force or gravity returns the piston rod.
Q: I have a drawing, could you customized cylinder as my drawing?
A: Sure. Show us the drawing, we will quote for you soonest.
Q: Could you make the cylinder which is not on the above data sheet?
A: Yes, we make and supply a wide rang of hydrualic cylinders as a proffetional manufacture, there are only some kinds of them show on the website. Freely contact us to get more information.
All technical indicators of HEISS PHU booster cylinders comply with German DIN and ISO international hydraulic standards, with standardized ratio grading and flexible customizable configurations to adapt to diverse industrial working conditions:
-
Driving Medium: Compressed air (standard industrial pneumatic pressure 0.4–1.0 MPa)
-
Output Medium: Standard mineral hydraulic oil (HL/HLP series); water-glycol flame-retardant fluid optional
-
Maximum Boost Pressure: Up to 250 bar hydraulic output according to different amplification ratios
-
Amplification Ratios: 4 standard boosting ratios available, with a maximum ratio up to 1:25 for ultra-high pressure output
-
Displacement Specifications: 7 standard volume displacement grades, covering small, medium and large flow demand scenarios
-
Maximum Stroke: Standard maximum working stroke up to 240 mm, supporting customized stroke optimization
-
Sealing Standard: Seal grooves strictly comply with ISO 5597/1 and DIN ISO 7425/1, ensuring long-term zero-leakage operation
-
Working Temperature Range: Standard sealing kit for -20°C to +80°C; high-temperature resistant Viton sealing version optional
Pneumatic Drive & Hydraulic Boost, High Energy Efficiency
The PHU cylinder uses common factory compressed air as power source to achieve hydraulic high-pressure amplification. It only consumes air pressure during pressure build-up and maintains pressure without continuous energy supply, greatly reducing air and power consumption compared with traditional hydraulic pump station systems. It effectively solves the problems of high energy consumption, high heat generation and large noise of conventional hydraulic systems.
Integrated Compact Structure & Easy Installation
Integrating pneumatic drive unit, hydraulic boosting unit and oil storage chamber into one compact body, the PHU series requires no additional hydraulic pump, motor, oil tank and complex pipeline layout. It features minimal installation dimensions, flexible mounting methods and simple on-site debugging, which greatly simplifies equipment structure and shortens production line transformation cycle.
Stable Pressure Holding & Excellent Repeatability
Adopting precision piston matching and high-performance sealing system, the booster cylinder realizes stable pressure build-up and long-term static pressure holding without pressure relief. The mechanical amplification structure ensures consistent output pressure and clamping accuracy in high-frequency cyclic work, with excellent repeat positioning and pressing stability.
Low Maintenance & Strong Environmental Adaptability
Free of vulnerable components such as hydraulic pumps and solenoid valves, the PHU cylinder has extremely low failure rate and long service life. The standardized detachable sealing structure supports quick maintenance and replacement. Customized versions such as high-temperature resistance, corrosion resistance and special medium adaptation can meet harsh working conditions of dust, high temperature and humid industrial workshops.
